弹簧平衡器
Model Capacity(kg) Travel (m) Cable diameter(Фmm) N.W  (kg) piece/canton The inside box's size (mm) The outer canton's size  (mm)
JTPH-A-3 1-3 1.5 3.2 1.5 5 220*180*75 405*235*205
JTPH-A-5 3-5 1.5 3.2 1.5 5 220*180*75 405*235*205
JTPH-A-9 5-9 1.5 4.2 4.5 4 245*235*180 510*258*395
JTPH-A-15 9-15 1.5 4.2 4.5 4 245*235*180 510*258*395
JTPH-A-22 15-22 1.5 5.2 8.5 1 / 388*310*232
JTPH-A-30 22-30 1.5 5.2 9 1 / 388*310*232
JTPH-A-40 30-40 1.5 5.2 11.5 1 / 388*310*232
JTPH-A-50 40-50 1.5 5.2 12 1 / 388*310*232
JTPH-A-60 50-60 1.5 5.2 12 1 / 388*310*232
JTPH-A-70 60-70 1.5 5.2 13.5 1 / 388*310*232
JTPH-A-80 70-80 1.5 5.2 13.5 1 / 388*310*232
JTPH-A-100 80-100 1.5 5.2 20.5 1 / 388*310*232
JTPH-A-120 100-120 1.5 5.2 21 1 / 388*310*232
JTPH-A-140 120-140 1.5 5.2 21 1 / 388*310*232
JTPH-A-160 140-160 1.5 5.2 22 1 / 388*310*232
JTPH-A-180 160-180 1.5 5.2 24 1 / 388*310*232
JTPH-A-200 180-200 1.5 5.2 26 1 / 388*310*232
