G100 Master Link Assembly with Flat（TH-1012）
Green painted.other colour is available as per request.
Working load limit permanently shown on the body.
Max proof load is 2.5 times of the working load limited.
Min.Breaking strength is 4 times of the W.L.L.
| Size | W.L.L | B.L | Dimension（mm） | Weight | |||||
| (t) | (t) | A | B | D | a | b | d | kg/pc | |
| 6-10 | 3 | 12 | 135 | 75 | 19 | 54 | 25 | 13 | 1.3 |
| 8-10 | 5.3 | 21.2 | 160 | 90 | 23 | 70 | 34 | 16.5 | 2.33 |
| 10-10 | 8 | 32 | 180 | 100 | 27 | 85 | 40 | 19 | 3.7 |
| 13-10 | 14 | 56 | 200 | 110 | 33 | 115 | 50 | 23 | 6.5 |
| 16-10 | 21.2 | 84.8 | 260 | 140 | 36 | 140 | 65 | 27 | 10.1 |
